Spray Pattern
●Hollow cone spray pattern
Spray angle
● 70°， 80°， 90°,wide angles available
Flow rates
● 1.3 gpm @ 30psi - 130 gpm @ 1000psi
Fine droplets: 50-120μm

Nozzle type: INTERNAL and external thread BSP or NPT

Interface size: 1/4", 1/8",1/2", 3/8", etc

High quality, corrosion resistance, wear resistance, spray stability
40-80° solid cone spray
working pressure of 40psi--1200psi
Mist Nozzles with Stainless-Steel Orifices
10/24” and 12/24” UNC thread size...

Material: Ss,Brass
Thread Size: 1/4"
Spray Pattern: Hollow Cone
Spray Angle: 35-91degree
Working Pressure: 2-70bar
...

Spray Pattern
●Hollow cone spray pattern
Spray angle
● 70°， 80°， 90°,wide angles available
Flow rates
● 1.3 gpm @ 30psi - 130 gpm @ 1000psi

Ordering Information
1/4LNN-SSS106
...

Spray Characteristics
● Spray pattern: full cone
● Spray angles: 60°
● Flow rate: 0.05 L/min- 0.2 L/min @70bar

Ordering Information:FP1
...

Spray Characteristics
● Spray pattern: full cone plume fog
● Spray angles: 90°to 120°
● Operating pressure: 5- 80 bar
● Flow rate: 0.051 L/min- 0.560 L/min @70bar

Ordering Information:1/4-IPM15
...

Some orifice:
0.15mm(.006"),0.2mm(.008"),0 .3mm(.012"),0.4mm(.016"),0 .5mm(.020")orifice

Thread size:
1/4", 1/8",1/2", 3/8", etc INTERNAL and external thread BSP or NPT

Spray shape: full cone
Droplet spray: less than 40 micron...

Spray Characteristics
● Spray pattern: full cone
● Spray angles: 60°
● Flow rate: 0.05 L/min- 0.2 L/min @70bar

Ordering Information:FP1
...

Spray Pattern
●Hollow cone
Spray angle
●80°
Flow rates
●0.55 gpm-2.85 gpm
Thread sizes
1/8“，1/4“
Pressure：10 to 80bar

Ordering Information:SC-M-2.00...

Thread size ：1/8" 10/24" 12/24" 3/16 inch  male NPT or BSPT
Material ：304Stainless Steel,Brass,Ceramic.brass plated
Orifice material and size：Stainless steel with ruby, 0.1mm-1.0mm
Spray angle：45-90 degree
Spray pattern：Fine misting, fogging
Commom application ： greenhouse humidification, oudoor misting.disinfecting.cooling.dust control.
Working pressure：20-100 bar...

Spray Pattern(s):Mist
Flow Range:.007 to 2.43 gpm
Pressure system: siphon
Pressure Range:50 to 1500 psi
Angle Range:1 - 120°
Common Materials:303, 316...

Material: stainless steel
Connection: external thread or internal thread
Thread connection: 1/8, 1/4, 3/8, 1/2, 3/4, 1 inch (complete model, available)
Spray: very fine 5-50 micron, 3-100 M spray distance
Application equipment: fog cannon, spray ring, spray equipment, etc
Function application: dust control, dust suppression, disinfection, atomization, humidification, cooling and so on
Application industry: coal mine, sand field, factory, garden, workshop, cleaning, etc...
